Dayton Model 1LNH1 DC Gear Motor, Degrees_Fahrenheit, to Volts, Amps, (
4.4 (15 items)
Limited Time SaleUS$46.57 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 221613314 | Release Date | 2026/05/03 | List Price | US$31.05 | Model Number | 221613314 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
DC gear motor, voltage 12Vdc, shaft orientation parallel, reversible shaft output no, Nameplate RPM 25, max. Torque 15 in.-Lb., overhung load 13 lb., input HP 1/150, gear ratio 172: 1, full load Amps 1.00, insulation Class b, enclosure TENV, thermal protection none, max. Ambient Temp. 40 Degrees C, rotation reversible, mounting all position, motor Type permanent magnet DC, Length less shaft 3-1/4", overall Length 4-1/16", bearings porous Bronze on gear case and motor, lubrication grease filled, gear Type spur, gear case die cast zinc, housing material die cast zinc, application food processing and restaurant equipment, vending, Valve actuators, switch gear, RPM range 16 to 30
- 1/150 hp, 25 rpm, 1.00 amps, 12 volts dc
- 15 torque inch pounds
- Rotation = reversible; shaft: 5/16" x 13/16"
- Over hung pounds = 13
- One year manufacture warranty
| UPC | 663001412052 |
|---|---|
| Model | 1LNH1 |
| Speed | 25 RPM |
| Voltage | 12 Volts |
| Brand Name | Dayton |
| Horsepower | 1.5 Kilowatts |
| Model Name | gear |
| Unit Count | 1.0 Count |
| Item Weight | 2 Pounds |
| Part Number | 1LNH1 |
| Manufacturer | Dayton |
| Material Type | Copper |
| Item Type Name | Dayton Model 1LNH1 DC Gear Motor |
| Global Trade Identification Number | 00663001412052 |
